GU Secury LogIQ A2 Automatic Multipoint Lock - 2 Deadbolts 1770mm x 20mm Radius Faceplate

GU Secury LogIQ A2 Automatic Multipoint Lock - 2 Deadbolts 1770mm x 20mm Radius Faceplate
GU
  • GU Secury LogIQ A2 Automatic Multipoint Lock - 2 Deadbolts 1770mm x 20mm Radius Faceplate
  • GU Secury LogIQ A2 Automatic Multipoint Lock - 2 Deadbolts 1770mm x 20mm Radius Faceplate
  • GU Secury LogIQ A2 Automatic Multipoint Lock - 2 Deadbolts 1770mm x 20mm Radius Faceplate
  • GU Secury LogIQ A2 Automatic Multipoint Lock - 2 Deadbolts 1770mm x 20mm Radius Faceplate
  • GU Secury LogIQ A2 Automatic Multipoint Lock - 2 Deadbolts 1770mm x 20mm Radius Faceplate
  • GU Secury LogIQ A2 Automatic Multipoint Lock - 2 Deadbolts 1770mm x 20mm Radius Faceplate
FREE DELIVERY on Orders Over £60 Plus VAT
£ 51.26

£51.26 INC VAT

Show price ex. VAT

RRP from: £78.85 Saving 35.0%

27
HOURS
03
MINUTES
26
SECONDS
left for delivery on Tuesday 23 December
Variations
Select Description
45/92
Select Backset
45mm
Select Case Height
195mm
Select Case Width
60mm
Select Centre Case
Latch & Deadbolt
Select Centres
92mm
Select Locking Point Dead Bolt
2
Select Spindle
Single
Select Price Group
500

Product Code:
L37280

37 items in stock
Quantity

Contact us now if there is insufficient stock and one of our sales team will be happy to help

Product Details

Product Information

The GU Secury LogIQ A2 is a multipoint locking system built around an automatic locking 20mm latchbolt mechanism that operates as soon as the door is closed, without requiring a manual throw of the bolts. The single spindle latch and deadbolt centre case has 92mm centres, accepts a euro profile cylinder and there are two other locking point deadlocks. In addition, the latch is reversible providing suitability for both left and right‑hand doors.

In normal operation: as the door closes, triggers in the frame actuate the automatic latchbolts, which extend and prevent reversal, thereby drawing the door securely into the frame; a subsequent turn of the key (from the outside) or use of the lever (from the inside) deadlocks the central bolt as required.

This version has a 20mm radius faceplate, is 1770mm long and is prepped ready for the addition of a separately available Secury A-Opener motor, which would allow automated latchbolt retraction via an access control system.

  • Radius faceplate 20mm x 1770mm
  • Door automatically locks when closed
  • Lever / Key operation internally
  • Key operation externally
  • Integral patented hold-back feature
  • Reversible centre latch and locking point latches

Sizes

Operation

Extra Information

Documentation







Servicing
