WINKHAUS AV4-F Heritage 2070 Auto Locking Latch 2 Hooks 20mm Radius 1770mm Length

FREE DELIVERY ON ALL ORDERS OVER £60*

FROM

£308.75 INC VAT

Show price ex. VAT

RRP from: £457.40 Saving 32.5%

Variations

Select Description

select

Select Backset

select

Select Case Height

193mm

Select Case Width

select

Select Centres

92mm

Select Handed

Non Handed

Select Spindle

Single

Select Centre Case

Latch Only

Select Locking Point Hooks

Select Notes

Cylinder positioned at eye level

Select Price Group

500

View Variations Table

Clear All

Quantity

Add to Basket

Product Information

The Heritage Autolock AV4 from Winkhaus is an automatic multi-point locking system which locks automatically when you pull the door closed and is designed for doors that need a traditional eye level cylinder pull locking point. This version adds improvements such as being non handed and a new hook design with increased operational tolerances.

Two solid anti-push back hooks automatically engage when the door is closed and then a central magnetic trigger activates to lock, the locking points and the lock can be opened externally by a quarter of a turn of the key to the euro cylinder - available separately. The AV4 meets the requirements of PAS24 and is approved by the Police ‘Secured by Design’ security initiative.

Please note that the Autolock AV4 can be upgraded to a motorised door locking system by using a blueMatic EAV4 motor or blueMatic EAV4+ motor, which allow the locked door to be opened from the inside as usual using the cylinder and unlocked from the outside using all potential-free access control systems.

Heritage cylinder position where a traditional eye-level cylinder pull would be
Non handed
92mm centres
Can be upgraded with an electronic motor
Auto-locking latch
20mm radius faceplate
