AVOCET Pioneer Caravan Lock Latch & Deadbolt With 2 Deadbolt

The AVOCET Pioneer Caravan Lock Latch & Deadbolt With 2 Deadbolt has 35mm backset, 92mm centres, 220mm case height, 50mm case width, is twin spindle and has a latch & deadbolt centre case.

It has twin spindles meaning that it can be used as either a straight forward lever/lever operation (using just the 92mm spindle) or as a split spindle (lever/pad) operation when using both the 92mm and 62mm spindles.


Accreditation
These products have corrosion resistance to EN1670: Grade 4 (240 hours NSS).

Identification
Usually has "AVOCET" stamped on the faceplate, has a short unit length (1,565mm) for use on caravan doors and the center case has a large cut out step in the top corner.

Gearbox
The latch & deadbolt gearbox has a twin spindle, a case height of 220mm and a case width of 50mm.

Additional Locking Points
In addition to the locking points within the gearbox, the full length strip has 2 dead bolt locking points.

Faceplate
16mm wide faceplate, ideal for use on UPVC & composite applications and is 1.565m long.

Locking Point Distances
Locking Point Distance A = 685mm
Locking Point Distance B = 715mm

Croppable
This full length unit is croppable to allow the strip height to be reduced to suit the door it is being installed into.

Handing
The latch can be reversed by removing the screw in the latch, taking the latch out, flipping it to the opposite hand, and refitting the screw.

Spung/Unsprung
The gearbox is unsprung and must be installed with sprung handles and / or a compatible spring cassette to ensure correct operation and reliable lever return.

Operation
Locking Method - A. Lift lever to engage locking mechanisms and then one full turn of the cylinder to lock. One full turn of the key then push down on the lever to unlock.

• 1565mm length for caravan doors
• Reversible centre latch
• 20mm deadbolt throw
• 35mm backset
• Suitable for lever/lever and lever/pad applications
• Endurance tested to 100,000 operations
